  • 688 ZZ/RS/OPEN
Product name : 688 ZZ/RS/OPEN
Product No. : Ball Bearing 688 8x16x4mm
←[Previous Product]              [Next Product]→
Details:


688 bearing has open, seals and shield types, and v-groove inner ring is available.

It widely used in precision instruments, micro motor, remote control model, etc industries.

Demesions:
Bearing No. 688, 688-ZZ, 688-2RS, 688Z, 688RS, 688 ZZ, 688 RS
Bore diameter (d) 8 mm
Outer diameter (D) 16 mm
Width (B) 4 mm
Basic Load Rating(N)
Dynamic(Cr) 1064
Static(Cor) 474
Max. Speed(RPM)
Grease 36000
Oil 43000
Weight(g)
Approx. 3.11
Grade P0, P6, P5
Radial Clearance C0, C2, C3
