Product name : MR105-Chrome Steel bearings
Product No. : Bearing MR105 5X10X3MM
Details:
MR105 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc
| Demesions: | |
| Bearing No. | MR105, MR105-ZZ, MR105-2RS, MR105Z, MR105RS, MR105 ZZ, MR105 RS |
| Bore diameter (d) | 5 mm |
| Outer diameter (D) | 10mm |
| Width (B) | 3 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 366 |
| Static(Cor) | 135 |
| Max. Speed(RPM) | |
| Grease | 50000 |
| Oil | 60000 |
| Weight(g) | |
| Approx. | 0.91 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
