Product name : MR148-Chrome Steel
Product No. : Bearing MR148 8x14x3.5mm
Details:
MR148 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc
| Demesions: | |
| Bearing No. | MR148, MR148-ZZ, MR148-2RS, MR148Z, MR148RS, MR148 ZZ, MR148 RS |
| Bore diameter (d) | 8 mm |
| Outer diameter (D) | 14 mm |
| Width (B) | 3.5 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 609 |
| Static(Cor) | 309 |
| Max. Speed(RPM) | |
| Grease | 38000 |
| Oil | 45000 |
| Weight(g) | |
| Approx. | 1.9 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
