Product name : 624 ZZ/RS/OPEN
Product No. : Ball Bearing 624 4x13x5mm
Details:
624 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
Demesions: | |
Bearing No. | 624, 624-ZZ, 624-2RS, 624Z, 624RS, 624 ZZ, 624 RS |
Bore diameter (d) | 4 mm |
Outer diameter (D) | 13 mm |
Width (B) | 5 mm |
Basic Load Rating(N) | |
Dynamic(Cr) | 1106 |
Static(Cor) | 390 |
Max. Speed(RPM) | |
Grease | 40000 |
Oil | 48000 |
Weight(g) | |
Approx. | 3.1 |
Grade | P0, P6, P5 |
Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
