Product name : 683 ZZ/RS/OPEN
Product No. : Ball bearing 683
Details:
683 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 683, 683-ZZ, 683-2RS, 683Z, 683RS, 683 ZZ, 683 RS |
| Bore diameter (d) | 3 mm |
| Outer diameter (D) | 7 mm |
| Width (B) | 2 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 264 |
| Static(Cor) | 90 |
| Max. Speed(RPM) | |
| Grease | 63000 |
| Oil | 75000 |
| Weight(g) | |
| Approx. | 0.32 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
