Product name : 696 ZZ/RS/OPEN
Product No. : Ball Bearing 696 6*15*5mm
Details:
696 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 696, 696-ZZ, 696-2RS, 696Z, 696RS, 696 ZZ, 696 RS |
| Bore diameter (d) | 6 mm |
| Outer diameter (D) | 15 mm |
| Width (B) | 5 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 1139 |
| Static(Cor) | 418 |
| Max. Speed(RPM) | |
| Grease | 40000 |
| Oil | 45000 |
| Weight(g) | |
| Approx. | 3.85 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
