Product name : 698 ZZ/RS/OPEN
Product No. : Ball Bearing 698 8*19*6mm
Details:
698 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | 698, 698-ZZ, 698-2RS, 698Z, 698RS, 698 ZZ, 698 RS |
| Bore diameter (d) | 8 mm |
| Outer diameter (D) | 19 mm |
| Width (B) | 6 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 1902 |
| Static(Cor) | 734 |
| Max. Speed(RPM) | |
| Grease | 36000 |
| Oil | 43000 |
| Weight(g) | |
| Approx. | 7.12 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
