Product name : 604 ZZ/RS/OPEN
Product No. : Ball Bearing 604 4x12x4
Details:
604 bearing has open, seals and shield types, and v-groove inner ring is available.
These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.
| Demesions: | |
| Bearing No. | 604, 604-ZZ, 604-2RS, 604Z, 604RS, 604 ZZ, 604 RS |
| Bore diameter (d) | 4 mm |
| Outer diameter (D) | 12 mm |
| Width (B) | 4 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 814 |
| Static(Cor) | 280 |
| Max. Speed(RPM) | |
| Grease | 48000 |
| Oil | 56000 |
| Weight(g) | |
| Approx. | 2.19 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
