Product name : MR85 bearing
Product No. : MR85 bearing 5x8x2mm
Details:
MR85 bearing has open, seals and shield types, and v-groove inner ring is available.
It widely used in precision instruments, micro motor, remote control model, etc industries.
| Demesions: | |
| Bearing No. | MR85, MR85-ZZ, MR85-2RS, MR85Z, MR85RS, MR85ZZ, MR85 RS |
| Bore diameter (d) | 5mm |
| Outer diameter (D) | 8mm |
| Width (B) | 2 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 262 |
| Static(Cor) | 96 |
| Max. Speed(RPM) | |
| Grease | 53000 |
| Oil | 63000 |
| Weight(g) | |
| Approx. | 0.25 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
Technical Data:
Part number rule
Dimension Tolerance
Radial clearance
Vibration
Grease
